| Ana | |
|---|---|
| Ürün serisi | Lexium MC12 multi carrier |
| Ürün ya da bileşen tipi | Longstator motor |
| Tamamlayıcı | |
|---|---|
| kurulum yönü | Düz |
| Peak force | 120 N |
| doğruluk | 0.03 repetitive 0.25 absolute |
| maximum number of carrier per controller | 130 |
| maximum length of track per controller | 40 m |
| maksimum çalıştırma hızı | 4 m/s |
| Maximum attraction force | 380 N |
| maksimum hızlanma | 120 m/s² |
| minimum distance between carriers | 0 m |
| Maximum number of carrier per segment | 6 |
| IP koruma derecesi | IP65 |
| uzunluk | 300,4 mm |
| Genişlik | 162,6 mm |
| Derinlik | 136 mm |
| Ürün ağırlığı | 7,9 kg |
| Paketleme üniteleri | |
|---|---|
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 26,000 cm |
| Package 1 Width | 20,000 cm |
| Package 1 Length | 59,500 cm |
| Package 1 Weight | 9,168 kg |
| Unit Type of Package 2 | P06 |
| Number of Units in Package 2 | 8 |
| Package 2 Height | 70,000 cm |
| Package 2 Width | 80,000 cm |
| Package 2 Length | 60,000 cm |
| Package 2 Weight | 84,344 kg |
| Sözleşme garantisi | |
|---|---|
| Garanti | 18 ay |
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
×
![]()
